Photo Stability Chamber(500TPS-2)

Photo Stability Chamber(500TPS-2)

TEMP: 15-50°CCapacity:500L
  • Item NO.:

    500TPS-2
  • Product Origin:

    CHINA
Product introduction


labonce-TPS series photo-stability chamber is equipped with visible and near-ultraviolet light tubes, can independently control the type of light source, and can real-time printing and recording of visible light and near-UV radiation. visible light and near ultraviolet can be set directly and adjusted automatically to precisely control both light sources.


Equipped with D65 light source, near ultraviolet wavelength 320-400nm;The light source of each layer is controlled independently;With three levels of user authority, audit trail;

Reference Standard: ICHQ1B、Chinese Pharmacopoeia 2020 edition;

Light source design: The use of reasonable light source top design, the shelves of different positions of the sample to receive the light source irradiation of good uniformity;

Insulation material: Overall high-density polyurethane foam technology, with good insulation and moisture retention performance;

Chamber Materials:The exterior is coated with high quality steel plate,The liner is made of mirror stainless steel 304, no pollution

Refrigeration system: Imported fully enclosed compressor, high efficiency, low noise, long service life;

Control system: Programmable color touch screen controller, with three levels of user rights and audit trail function;more than 7 inches;With three levels of user authority, audit trail;

Data management :Configure needle type micro printer and electronic data storage function,support to use U disk to export the data.

 Safety device: Compressor overheat and overpressure overload protection, independent overtemperature protection alarm system;

Alarm system:On-site beeping alarm;

Double Door Structure:Interior door tempered glass door,Open the outer door to observe the samples,The temperature inside the container will not change in a short time,The outer door is solid can keep temperature,It can also prevent the influence of external light;

Other configurations:Test hole、Rubber plug、Mobile casters; Door lock;

 Illumination open:Temperature Fluctuation < ±1.0℃,

 Temperature deviation of the same layer: < ±2.0℃ ;

Environment Temperature:+5 ~ 35℃ ;

Power:AC220V±10% 50HZ;

Optional: Temperature-humidity deviation, sudden power failure , control by Remote SMS alarm.


Model

Temperature Range

( ℃ )

Capacity

(L)

Interior Dimensions(mm)

W×D×H

External Dimensions(mm)

W×D×H

Power

( kW )

Remarks

Labonce-150TPS-1

15 ~  50

150

650×490×500

830×790×1250

1.2

1   layer of light,

Visible Light+UVA

Labonce-300TPS-2

15 ~  50

300

550×660×770

850×1030×1570

1.5

2  layers of light,

Visible Light+UVA

Labonce-500TPS-2

15 ~  50

500

660×680×1110

880×1080×1880

1.8

2  layers of light,

 Visible Light+UVA

Labonce-500TPS-3

15 ~  50

500

660×680×1110

880×1080×1880

2.1

3  layers of light,

Visible Light+UVA

Labonce-1000TPS-3

15 ~  50

1000

1360×490×1360

1620×910×1990

2.5

3  layers of light,

Visible Light+UVA

Labonce-150LTPS-1

2 ~ 30

150

650×490×500

830×790×1250

1.5

1   layer of light,

Visible Light+UVA

Labonce-500LTPS-2

2 ~ 30

500

660×680×1110

880×1080×1880

2.1

2  layers of light,

Visible Light+UVA

Remarks

TPS:Visible Range100 ~  8000Lux,Direct SettingIlluminance deviation:4500±500LuxUVA range0.84 ~  5w/m2;        LTPS:Visible Range100 ~  5000Lux,Direct SettingIlluminance deviation:4500±500LuxUVA range0.84 ~ 1w/m2;        Illumination requirementsThe total illumination is not less than 1.2×106  Lux •hr; UVA energy is not less than 200w •hr/ m2.
