Humidity:40~95%RH Capacity:150L~500L
Read moreItem NO.:
250GSProduct Origin:
CHINALabonce-GS Medicine Stability Testing Chamber, Adopt imported with frequency conversion technology design, Choose the original imported high quality parts, Stable and reliable performance,Suitable for GMP and CGMP certified users.
❶ |
Reference Standard:ICHQ1(A)、Chinese Pharmacopoeia 2020 edition; |
❷ |
Insulation material: Overall high-density polyurethane foam technology, with good insulation and moisture retention performance; |
❸ |
Chamber Materials:The exterior is coated with high quality steel plate,The liner is made of mirror stainless steel 304, no pollution source, easy to clean; |
❹ |
Control system: Programmable color touch screen controller; |
❺ |
Three Level Authority:Adopt the user name and password to log in. Different user names have different permissions at least three levels or above; |
❻ |
Audit tracking: The control system has historical alarm recording and operation recording functions, and supports exporting in an unchangeable file format using a USB flash drive; |
❼ |
Refrigeration system: Imported fully enclosed compressor; |
❽ |
Humidity control: Original imported capacitive humidity sensor, high precision, low drift, long service life, maintenance free; |
❾ |
Data management: configuring needle micro printers and electronic data storage functions; |
❿ |
Safety device: Compressor overheat and overpressure overload protection, water shortage protection, Anti dry burning protection system, independent overtemperature protection alarm system; |
⓫ |
Alarm system:On-site beeping alarm; |
⓬ |
Double Door structure:Interior door tempered glass door,Open the outer door to observe the sample,The temperature and humidity inside the container will not change in a short time,The outer door is solid can keep temperature and humidity,It can also prevent the influence of external light; |
⓭ |
Controlling Temperature Precision:Temperature Fluctuation<±0.5℃;Temperature Deviation <±1.0℃ ; |
⓮ |
Controlling Humidity Precision:Humidity Fluctuation < ±2%RH;Humidity Deviation < ±3%RH; |
⓯ |
Power:AC220V±10% 50HZ; |
⓰ |
Environment Temperature:+5 ~ 35℃ ; |
⓱ |
Optional: Temperature- humidity deviation, sudden power failure ,Remote SMS alarm.
|
Model |
Temperature Range ( ℃ ) |
Humidity Range (RH) |
Capacity (L) |
Interior Dimensions(mm) W×D×H |
External Dimensions(mm) W×D×H |
Power ( kW ) |
Shelf (Standard) |
Labonce-150GS |
10 ~ 65 |
20 ~ 95% |
150 |
600×405×620 |
780×830×1480 |
1.2 |
3 |
Labonce-250GS |
10 ~ 65 |
20 ~ 95% |
250 |
600×500×830 |
780×880×1650 |
1.5 |
3 |
Labonce-400GS |
10 ~ 65 |
20 ~ 95% |
400 |
600×700×950 |
780×1060×1750 |
2.0 |
3 |
Labonce-500GS |
10 ~ 65 |
20 ~ 95% |
500 |
680×680×1080 |
860×1050×1850 |
2.2 |
4 |
Previous :
Stability Chamber(400L)Next :
Stability Chamber(medicine packages250L-500L)Labonce-GS Medicine Stability Testing Chamber, Adopt imported with frequency conversion technology design, Choose the original imported high quality parts, Stable and reliable performance,Suitable for GMP and CGMP certified users. ❶ Reference Standard:ICHQ1(A)、Chinese Pharmacopoeia 2020 edition; ❷ Insulation material: Overall high-density polyurethane foam technology, with good insulation and moisture retention performance; ❸ Chamber Materials:The exterior is coated with high quality steel plate,The liner is made of mirror stainless steel 304, no pollution source, easy to clean; ❹ Control system: Programmable color touch screen controller; ❺ Three Level Authority:Adopt the user name and password to log in. Different user names have different permissions at least three levels or above; ❻ Audit tracking: The control system has historical alarm recording and operation recording functions, and supports exporting in an unchangeable file format using a USB flash drive; ❼ Refrigeration system: Imported fully enclosed compressor; ❽ Humidity control: Original imported capacitive humidity sensor, high precision, low drift, long service life, maintenance free; ❾ Data management: configuring needle micro printers and electronic data storage functions; ❿ Safety device: Compressor overheat and overpressure overload protection, water shortage protection, Anti dry burning protection system, independent overtemperature protection alarm system; ⓫ Alarm system:On-site beeping alarm; ⓬ Double Door structure:Interior door tempered glass door,Open the outer door to observe the sample,The temperature and humidity inside the container will not change in a short time,The outer door is solid can keep temperature and humidity,It can also prevent the influence of external light; ⓭ Controlling Temperature Precision:Temperature Fluctuation<±0.5℃;Temperature Deviation <±1.0℃ ; ⓮ Controlling Humidity Precision:Humidity Fluctuation < ±2%RH;Humidity Deviation < ±3%RH; ⓯ Power:AC220V±10% 50HZ; ⓰ Environment Temperature:+5 ~ 35℃ ; ⓱ Optional: Temperature- humidity deviation, sudden power failure ,Remote SMS alarm. Model Temperature Range ( ℃ ) Humidity Range (RH) Capacity (L) Interior Dimensions(mm) W×D×H External Dimensions(mm) W×D×H Power ( kW ) Shelf (Standard) Labonce-150GS 10 ~ 65 20 ~ 95% 150 600×405×620 780×830×1480 1.2 3 Labonce-250GS 10 ~ 65 20 ~ 95% 250 600×500×830 780×880×1650 1.5 3 Labonce-400GS 10 ~ 65 20 ~ 95% 400 600×700×950 780×1060×1750 2.0 3 Labonce-500GS 10 ~ 65 20 ~ 95% 500 680×680×1080 860×1050×1850 2.2 4
Labonce -C Series Low -temperature Stability Chamber,Adopt the brand - new air-way structural design, select the original imported high quality parts and manufacturing process, ensure the long -term continuous operation of the equipment, stable and reliable performance, suitable for temperature sensitive medicine stability test and preservation. ◆ Reference Standard:Medical refrigerator industry standard: YY/T 0086-2020; ◆ Air-way System: The newly air-way system designed achieves uniform of temperature form different parts inside the chamber; ◆ Insulation material: Overall high-density polyurethane foam technology, with good insulation and moisture retention performance; ◆ Chamber Materials:The exterior is coated with high quality steel plate,The liner is made of mirror stainless steel 304, no pollution source, easy to clean; ◆ Refrigeration system:Imported fully enclosed industrial compressor, high efficiency, low noise, long life; ◆ Control system:Original imported digital display controller, high precision, low drift; ◆ Safety device: compressor overheat and overpressure overload protection; ◆ Alarm system:On-site beeping alarm; ◆ Other configuration:Test hole、Rubber plug、Mobile casters、Door lock; ◆ Controlling Temperature Precision:BC:Temperature Fluctuation < ±1.0℃;Temperature Deviation < ±2.0℃;Temperature Uniformity ≤ 2.0℃ ; RC:Temperature Fluctuation < ±0. 5℃;Temperature Deviation < ±1.0℃ ; Temperature Uniformity ≤ 1.0℃ ; FC:Temperature Fluctuation < ±0. 5℃;Temperature Deviation < ±2.0℃ ; Temperature Uniformity ≤ 2.0℃ ; ◆ Environment Temperature:+5 ~ 30℃ ; Power:AC220V±10% 50HZ; ◆ Optional: Temperature- humidity deviation, sudden power failure , control by Remote SMS alarm. Name Model Temperature Range ( ℃ ) Capacity (L) Interior Dimensions(mm) W×D×H External Dimensions(mm) W×D×H Power ( kW ) Shelf (Standard) Remarks Storage Chamber (2~14℃ ) Labonce-250BC 2~14 250 600×500×830 780×880×1650 0.6 3 With observation window Labonce-400BC 2~14 400 600×700×950 780×1060×1750 0.8 3 Labonce-500BC 2~14 500 680×680×1080 860×1050×1850 1.0 4 Labonce-800BC 2~14 800 1200×490×1360 1390×890×1960 1.2 4 Labonce-1000BC 2~14 1000 1400×510×1400 1590×890×1980 1.5 4 Low-temperatre Chamber(5℃ ) Labonce-250RC 5 250 600×500×830 780×880×1650 0.6 3 With observation window,Double compressors, one operation and one protection. Labonce-500RC 5 500 680×680×1080 860×1050×1850 1.2 4 Labonce-720RC 5 750 1200×490×1360 1390×890×1960 1.5 4 Labonce-2000RC 5 2000 1500×970×1400 1710×1380×1990 2.0 4 Low-temperatre Chamber(-20℃ ) Labonce-150FC -20 150 600×405×620 850×890×1520 1.0 3 Solid door Labonce-250FC -20 250 600×500×830 850×990×1690 1.5 3
