Labonce Walk-In Stability Chamber
Product categories
Latest product
Stability chamber320LGS,Stability chamber520LGS

Temperature & humidity with light Stability chamber(Two boxes are independently controlled)

Humidity:10~90%RH Capacity:300L~500L
  • Item NO.:

    320LGS/CGS~520LGS/CG
  • Product Origin:

    CHINA
Product introduction

Labonal-LGS /LCGS series two boxes of comprehensive medicine stability test box, adopt imported process design, two boxes of independent control, A box has four functions of temperature and humidity visible light near ultraviolet, and can timely record visible light and near ultraviolet irradiance. B box control and record the temperature and humidity, only can do the limit of 60 ℃ / 10% RH condition, special medicine packaging material test.
 Capacity: 300L~500L

Temperature Range:15~65℃, Fluctuation:±0.5℃, Deviation: ±1.0℃(No light)

Humidity Range: 40~95%RH,Fluctuation:±3.0%RH, Deviation: ±3.0%RH

Light Range:Visible light range:100-8000LUX;Total illumination not less than 1.2*10^6Lux.HR

UV Range :Near ultraviolet range :0.84-5w/㎡;near-ultraviolet energy  is no  less than 200w·hr/㎡

UV Wavelength:near ultraviolet wavelength:320-400nm;

Illumination Control:The four parameters of temperature humidity,visible light and near-ultraviolet are centrally controlled on a touch screen controller

Illuminance Printing: It can print four values of temperature, humidity, visible light and near-ultraviolet at the same time.

Temperature and Humidity controller:Original imported color touch screen controller,5 inches above, program control, with three-level permission code;

Humidity Sensor:Imported VAISALA capacitive humidity sensor, which is directly detected without maintenance;

Refrigeration Compressor: Full-closed compressor imported from original, long time, low noise;

Data Printing: The type and number of equipment can be printed, temperature and humidity value and curve can be printed at the same time.

Data Storage: Can store temperature and humidity over 5 years;

On-site Alarm: On-site temperature and humidity deviation sound-light alarm, independent over-temperature alarm;

Remote Alarm: Remote SMS alarm (with power outage), multiple devices can share one mobile card;

Box Material:The inner liner material is stainless steel 304, and the outer shell material is quality steel plate.

Double Door structure:A toughened glass door is built in for easy observation; The outer door is completely closed to shield the influence of external light.

Double Protection: Double insurance and dry burning protection system; Equipped with independent overtemperature protection system, the power can be cut off automatically.

Safety Device: Compressor overheat protection, compressor overpressure protection, compressor overheat protection and fan overheat protection.

Installation Power: AC 220V± 10% 50HZ;

Working Environment: + 5 ~ 35 ℃ (best can control within 30 ℃, using the limit under the condition of control within 26 ℃);

Special Note:The relevant printing parameters on the color pages are different from the description on the page.

MODEL

TEMP RANGE

(℃ )

HUMI RANGE

(RH)

CAPACITY

(L)

INTERNAL DIMEN(mm)

W×D×H

EXTERNAL DIMEN (mm)

W×D×H

POWER

(kw)

TRAY

REMARKS

Labonce-320LGS

10 ~ 65

10~ 90%

150

480×410×760

1320×780×1560

2.5

3

A

150

480×410×760

3

Labonce-520LGS

10 ~ 65

10~ 90%

250

600×500×830

1560×870×1650

3.0

3

250

600×500×830

3

Labonce-320LCGS

15 ~ 65

10~ 90%

150

480×410×760

1320×780×1560

2.5

3

A

150

480×410×760

3

Labonce-520LCGS

15 ~ 65

10~ 90%

250

600×500×830

1560×870×1650

3.0

3

250

600×500×830

3
